Fiber Optic Pigtail SC FC LC APC UPC Sm 1m 1.5m 0.9mm G652d G657A PVC LSZH
Type：
Product Feature：
Model No: LC SM DX
Jacket : PVC/LSZH, PVC or LSZH
Length : 1M/2M/3M So on
Connector Type : SC/LC/ST/FC
Insertion loss : ≤0.20, MM≤0.75dB, SM≤0.50dB, ≤0.1dB, IL<0.2db
Connector : FC, SC, SC/APC (LC, LC, FC for choice)
Fiber type : SM 9/125 G652D, OS1, 9/125 tight buffered fiber Single Mode simplex, G652D/G657A1/G657A2 etc., G657A1 etc.
Cable diameter : 0.9/2.0/3.0mm, 3mm, 0.9mm, 2mm
Jacket material : Customize, can be customized, 1M; 2M; 4M etc., 10Meter
Fiber Optic Pigtail SC FC LC APC UPC Sm 9/125 1m 1.5m 0.9mm G652d G657A PVC LSZH Fiber Pigtail
Fc Pigtail Quick Detail:
- Cable jacket: PVC, LSZH, OFNP, OFNR
- Cable color: Yellow, Orange, Aqua, White, Red, Green, 12corlors
- Insertion loss: ≤0.2dB for SM, ≤0.3dB for MM and SM/APC
- Return loss: ≥ 45 dB for PC, ≥ 50 dB for UPC, ≥ 65 dB for APC and ≥35dB for MM
- Cable length: 1m, 2m, 3m, 5m....customized
- Cable core: simplex, duplex, 6core,12core, 24core, 48core… customized
Specification:
| Parameter | Single Mode | Multi Mode |
| Basic | Fiber connector | FC, SC, LC, ST, MU, MTRJ, MPO |
| Ferrule End-face | PC | UPC | APC | UPC |
| Insertion Loss | ≤0.2dB | ≤0.2dB | ≤0.3dB | ≤0.3bB |
| Return Loss | ≥50dB | ≥55dB | ≥60dB | ≥35dB |
| Ceramic Ferrule Specification | 125.5um concentricity deviations:<=1um | 127um concentricity deviations:<=3um |
| Suitable Fiber | 9/125um | 50/125um,62.5/125um |
| End-face Geometry | Radius of Curvature | 7~25mm | 5~12mm | N/A |
| Fiber Protrusion | ≤50nm | ≤100nm | N/A |
| Fiber Under Cut | ≤100nm | ≤100nm | N/A |
| Apex offset | ≤50um |
| Mechanical | Exchangeability | ≤0.2dB |
| Salt Spray | ≤0.1dB |
| Drop | ≤0.2dB(1.5M, 5 drops) |
| Vibration | IL ≤0.2dB(550Hz, 1.5mm) |
| Repeatability | ≤ 0.1dB(1000 times) |
| Durability | > 1000 times |
| Operating Temperature | -40°C ~ +85°C |
Description:
Fiber Optic Pigtail is with one piece construction and pulls proof design. Low cost but high performance, which
makes it one of the most popular cables.
Features:
- 100% test before shipment
- Low insertion loss and high return loss
- Custom Configurations Available at No Extra Charge
- Available in fiber bunch, ribbon fan-out, pigtail available
- Serialized & Individual Test Records
- Meets ROHS and Bell core GR 326-core standards
Applications:
- FTTH application
- Premise installations
- Data processing networks
- Wide Area Networks (WANs)
- Industrial ,mechanical and military
