Vibration test
Test criterion：IEC 61300-2-1
Amplitude：0.75mm
Frequency sweep range：10~50HZ/minute
Time：30minutes
After test：
a.No mechanical damage, such as deformation, crack, slack, etc
b.The optical performance conforms to Table 5
2.Impact test
Test criterion：IEC 61300-2-12
Drop height：1.5m
Drop times：5 /times
After test：
a.No mechanical damage, such as deformation, crack, slack, etc
b.The optical performance conforms to Table 5
3.Mating durability test
Test criterion：IEC 61300-2-2
Durability：500 /times
After test：
a.No mechanical damage, such as deformation, crack, slack, etc
b.The optical performance conforms to Table 5
4.Environmental performances
High temperature test
Test criterion：IEC61300-2-18
Temperature：70℃
Time：96 /hours
After test：
a.No mechanical damage, such as deformation, crack, slack, etc
b.The optical performance conforms to Table 5
5.Low temperature test
Test criterion：IEC61300-2-17
Test criterion：-25℃
Time：96 /hours
After test：
a.No mechanical damage, such as deformation, crack, slack, etc
b.The optical performance conforms to Table 5
6.Change of temperature：
Test criterion：IEC 61300-2-22
Temperature range：-25℃to + 70℃
Time：96 /hours，12 /cycles
After test：
a.No mechanical damage, such as deformation, crack, slack, etc
b.The optical performance conforms to Table 5
7.Damp heat
Test criterion：IEC 61300-2-19
Test condition：40℃，93% RH
Time：96 /hours
After test：
a.No mechanical damage, such as deformation, crack, slack, etc
b.The optical performance conforms to Table 5
No. | Test Item | Insertion Loss variation（dB） |
1 | Vibration test | ≤0.2 |
2 | Impact test | ≤0.2 |
3 | Mating durability test | ≤0.2 |
4 | High temperature test | ≤0.2 |
5 | Low temperature test | ≤0.2 |
6 | Change of temperature | ≤0.2 |
7 | Damp heat | ≤0.2 |
Temperature Performances
Opration temperature: -25℃～+70℃
Installation temperature: -10℃~+60℃
Storage temperature: -40℃~+85℃
